M1 Enclosure Developer Docs

The M1 Enclosure is a rugged, IP67-rated weatherproof case designed to securely house Particle Tachyon, Muon, or Raspberry Pi-compatible boards. It provides robust environmental protection, flexible mounting options, and integrated connectivity features.

M1 Enclosure Open

Overview​

The M1 Enclosure makes it easy to deploy your Tachyon, Muon, or Raspberry Pi projects in the field. Designed with expandability in mind, it features integrated mounting for expansion HATs, pass-through cutouts for USB-C, PCIe, DSI, and CSI cables, and internal space for accessories such as a GNSS antenna or battery.

🔧 Key Features​

  • Rugged, Weatherproof Design → IP67-rated for outdoor and industrial applications.
  • Carrier Board Support → Secures Raspberry Pi-compatible boards using pin headers and screws.
  • I/O & Expansion → Provides USB-C, PCIe, DSI, and CSI cutouts for easy access.
  • Built-in Status LEDs & Button → External RGB LED indicators and a user-configurable button.
  • Antenna Mounting → Includes two SMA connectors for external antennas.
  • Flexible Mounting Options → Can be mounted on walls, poles, rails, or magnetic surfaces.
  • Bulkhead Connectivity → Includes two M20 holes for cable glands, plugs, or additional connectors.
